SPECIFICATIONS

Wallpaper Setting: 3 wallpapers

Voltage: 12V

Touch Screen: 4.1 inch resistive type touch screen

Standby Time Setting: Standby time setting

Special Features: Radio Tuner

Resolution: 800*480

Radio Response Bandwidth: 87.5MHz - 108.0MHz

Placement: In-Dash

Out Power: 4*45W

Origin: Mainland China

OSD Language: English

Model Name: 7805C

Menu Language: Multilanguage

Media Interface: USB, TF, Aux

Material Type: Metal and plastic

Item Weight: 0.6kg

Item Size: 1 Din

Display Size: 4"

Charging: USB fast charging for cell phone

Certification: CE

Button Light Color: Red, blue, green, yellow, purple, cyan, purple and white

Brand Name: PHYEE

Bluetooth: Bluetooth A2DP music, Bluetooth handsfree

Touch Screen Car Radio 1 Din Bluetooth Music Handsfree MP5 Player TF USB Charging Remote Audio System ISO 4.1” Head Unit 7805C

Spain Warehouse Delivery NOTICE:

* NO delivery service for islands with Spanish postcodes beginning with 35, 38, 51, 52!

* NO delivery service for islands with Portuguese postcodes beginning with 9!

* NO delivery services in regions where the French postcode starts with 97!









Good sound quality

4 channels digital audio processing chip for balance, treble, bass, loudness setting. 4CH*45W high power amplifier chip.





Low power consumption Bluetooth 4.0, more environmentally friendly

90% lower power consumption than the old version, handsfree for safe driving and A2DP stereo music playback.







Global FM radio area selection

Support FM frequency for Europe, Japan, North America, Latin America, Mid-East and so on.







Charge cell phone as you want

USB charging port max 2.1A output current, which is enough for mobile phone charging.







Panel lighting color more matching car dashboard

Red, blue, green, yellow, purple, cyan, white, you can find the one you like.





Blue screen / flashing screen problem

Accessories

Touch screen car radio head unit 7805C
Big remote control (without battery, using AAA battery)
ISO connector cables
User manual
Rear view camera (optional)

FAQ

Q: How to do the power part wiring?

The ISO harness pin A4 wire is connected to car battery 12V (constant 12V). The ISO harness pin A7 wire is connected to ACC (car ignition switch 12V). The ISO harness pin A8 wire is connected to car battery negative pin (ground).

Q: How to connect the Rear View Camera?

The ISO harness pin A1 wire is the rear view camera input signal control wire.Please connect it to car reverse light switch wire.

If you connect the rear view camera signal control wire to power, the car radio will enter reverse mode (blue screen or flashed screen).

Q: Blue Screen (Why the screen flashing when car moves)?

This is because the ISO harness pin A1 wire is connected to 12V and the car radio enters the reversing mode. The solution is to cut off pin A1 wire.

Q: No sound or heat up very quickly?

Because there is a short circuit between the speaker and the ground (Please check the car speaker whether has only one output wire. Because some old car speaker only has one wire and it is positive, and the speaker shell is negative. If your car is like this, you need to contact a wire on the speaker shell, so that there will be no rapid heating question), the output current of the car radio increases (heat up quickly).

It is also possible that there is a circuit between the speaker wire and the power supply, causing the power amplifier IC to enter a protection state (no sound).

So please check the speaker pin wire connection at first.

Q: The car radio can't work well?

Please reset the car radio via clicking the reset button (a little hole with "RES" word on front panel).

Q: Is car radio fixed panel or removable panel?

The car radio panel is fixed.

Q: Does car radio support external microphone?

The car radio doesn't support external microphone.

Q: Car radio instllation size?

This car radio body is standard 1 Din size (50mm*178mm).

Q: RCA Audio Output?

This car radio has RCA audio output which is full audio frequency and can't be adjustable. They can be connected to external subwoofer with amplifier function.
